SMART-HORIZON directional antenna
- Frequency: 2.4 - 2.5 GHz
- Gain: 18 dBi
- Beamwidth: 65° horizontal / 30° vertical
- Connector: N-type female
- Polarization: Linear vertical
SMART-HORIZON directional antenna
The SMART-HORIZON directional antenna is designed for long-range wireless communication in the 2.4 GHz ISM band. With a high gain of 18 dBi and a narrow beamwidth of 65° horizontal and 30° vertical, it focuses the signal in a specific direction, reducing interference and extending the transmission distance. This antenna is ideal for point-to-point links, WiFi bridging, and outdoor access points where reliable connectivity over several kilometers is required.
Constructed with a durable UV-resistant radome and a corrosion-resistant aluminum reflector, the SMART-HORIZON withstands harsh outdoor environments. It features an N-type female connector for easy integration with standard RF cables and lightning arrestors. The antenna supports linear vertical polarization and can be mounted on a pole or wall using the included hardware. Its compact design and lightweight construction simplify installation while maintaining robust performance.
| Frequency Range | 2.4 - 2.5 GHz |
| Gain | 18 dBi |
| Beamwidth (Horizontal) | 65° |
| Beamwidth (Vertical) | 30° |
| Polarization | Linear vertical |
| Connector | N-type female |
| Impedance | 50 ohms |
| VSWR | < 1.5:1 |
| Front-to-Back Ratio | > 25 dB |
| Maximum Power | 100 W |
| Dimensions | 600 x 400 x 150 mm |
| Weight | 2.5 kg |
| Operating Temperature | -40°C to +70°C |
-
